EPRexLS  MV-105, EPR/CTS/PVC Power, Type MV-105, 5kV-35kV

Series E8 - Medium Voltage, EPR/Cu Tape Shield/PVC, Type MV-105 Cable consist of fully annealed bare copper Class B stranded conductors, covered with ethylene propylene rubber (EPR), copper tape shield, and black PVC jacket. These cables are used in industrial power circuits.

EPRexLS  MV-105, EPR/CTS/TP-CPE Power, Type MV-105, 5kV-35kV

Series E8 - Medium Voltage, EPR/Cu Tape Shield/CPE, Type MV-105 Cable consists of fully annealed bare copper Class B stranded conductors, covered with ethylene propylene rubber (EPR), copper tape shield and black CPE jacket. These cables are used in industrial power circuits.

EPRexLS  MV-105, EPR/CTS/PVC Power, Type MV-105, 5kV–35kV

Series E8 - Medium Voltage, EPR/Cu Tape Shield/PVC, Type MV-105 Cable consist of Aluminum Class B stranded conductors, covered with ethylene propylene rubber (EPR), copper tape shield, and black PVC jacket. These cables are used in industrial power circuits.

EPRexLS  MV-105, EPR/CTS/PVC Power, Type MV-105, 3 Conductor, 5kV-15kV

Series E8 - 3 Conductor MV-105 Power Cables consist of fully annealed bare copper Class B stranded conductors, covered with ethylene propylene rubber (EPR), copper tape shield, and black PVC jacket. These cables are used in industrial power circuits.

EPRexLS  MV-105, EPR/CTS/TP-CPE Power, Type MV-105, 3 Conductor, 5kV-15kV

Series E8 - 3 Conductor MV-105 Power Cables consists of fully annealed bare copper Class B stranded conductors, covered with ethylene propylene rubber (EPR), copper tape shield and black CPE jacket. These cables are used in industrial power circuits.

Product Specification Sheets

For a full list of our product spec sheets, please click here.

TR-XLPE/CN/LLDPE, MV-90 Type Primary UD, 15kV–35kV

Series E9 (Aluminum Conductors)

Medium Voltage Primary Underground Distribution (UD) cables consist of an Aluminum (filled or unfilled) conductor, covered with tree-retardant Cross-linked polyethylene (TR-XLPE), a concentric neutral of helically applied copper wires, and a linear low-density polyethylene (LLDPE) jacket with 3 extruded red stripes.

TR-XLPE/CN/LLDPE, MV-90 Type Primary UD, 15kV–35kV

Series E9 (Aluminum Solid Conductor)

The Medium Voltage Primary Underground Distribution (UD) cables consist of an Aluminum Solid conductor, covered with tree-retardant Cross-linked polyethylene (TR-XLPE), a concentric neutral of helically applied copper wires, and a linear low-density polyethylene (LLDPE) jacket with 3 extruded red stripes.

TR-XLPE/CN/LLDPE, MV-90 Type Primary UD, 15kV–35kV

Series E9 (Copper Conductors)

Medium Voltage, EPR/Cu Tape Shield/PVC, Type MV-105 Cable consist of Aluminum Class B stranded conductors, covered with ethylene propylene rubber (EPR), copper tape shield, and black PVC jacket. These cables are used in industrial power circuits.

EPR/CN/LLDPE, MV-90 Type Primary UD, 15kV–35kV

Series E9 (Aluminum Conductors)

Medium Voltage Primary Underground Distribution (UD) cables consist of an Aluminum (filled or unfilled) conductor, covered with ethylene propylene rubber (EPR), a concentric neutral of helically applied copper wires, and a linear low-density polyethylene (LLDPE) jacket with 3 extruded red stripes.

EPR/CN/LLDPE, MV-90 Type Primary UD, 15kV–35kV

Series E9 (Aluminum Solid Conductor)

Medium Voltage Primary Underground Distribution (UD) cables consist of an Aluminum Solid conductor, covered with ethylene propylene rubber (EPR), a concentric neutral of helically applied copper wires, and a linear low-density polyethylene (LLDPE) jacket with 3 extruded red stripes.

EPR/CN/LLDPE, MV-90 Type Primary UD, 15kV–35kV

Series E9 (Copper Conductors)

Medium Voltage Primary Underground Distribution (UD) cables consist of a Copper (filled or unfilled) conductor, covered with ethylene propylene rubber (EPR), a concentric neutral of helically applied copper wires, and a linear low-density polyethylene (LLDPE) jacket with 3 extruded red stripes.

Product Specification Sheets

For a full list of our product spec sheets, please click here.
